Ict Billet An920-10-10A An-To-Orb O-Ring Adapter Fitting – Precision Machined

Description

Brand: ICT Billet
Manufacturer’s Part Number: AN920-10-10A
Part Type: Fittings and Adapters
Product Line: ICT Billet AN to Straight Thread O-Ring (ORB) Adapter Fittings
Automotive Fittings Part Number: ICB-AN920-10-10A
UPC: 00797822585784
Fitting Style: Adapter
Fitting Category: AN to Straight cut O-ring
Fitting Angle: Straight
Fitting Material: Aluminum
Fitting Color: Natural
Swivel: No
Gauge Port: No
O-Rings Included: No
Fitting Attachment 1: Male AN
Fitting Size 1: -10 AN
Fitting Attachment 2: Male straight cut O-ring
Fitting Size 2: -10 AN
Quantity: Sold individually.
Description:
ICT Billet AN to straight thread O-ring (ORB) adapter fittings connect AN threaded flexible hoses or rigid metal tubing to straight thread O-ring boss fittings. ORB fittings are recommended for optimal leakage control in medium and high-pressure fluid systems. The seal takes place by compressing the O-ring; the threads hold the connection mechanically. ICT Billet adapter fittings are available in a variety of sizes and finishes.
